1600 Series Deep Groove Ball Bearings
Short Description:
● 1600 Series Deep groove ball is one of the most widely used rolling bearings.
● Low friction resistance, high speed.
● Simple structure, easy to use.
● Applied to gearbox, instrument and meter, motor, household appliance, internal combustion engine, traffic vehicle, agricultural machinery, construction machinery, construction machinery, roller roller skates, yo-yo ball, etc.
I have all the models you need, these are just some of them, please contact us now
No. | Dimensions (Inch) | Wgt. (lbs.) | Interchange |
d | D | B |
1601 | 0.1875 | 0.6875 | 0.25 | 0.025 | BR-01 | 21103-00 | 1601 NS |
1602 | 0.25 | 0.6875 | 0.25 | 0.025 | BR-02 | 21104-00 | 1602 NS |
1603 | 0.3125 | 0.875 | 0.2812 | 0.033 | BR-03 | 21405-00 | 1603 NS |
1604 | 0.375 | 0.875 | 0.2812 | 0.04 | BR-04 | 21406-00 | 1604 NS |
1605 | 0.3125 | 0.9062 | 0.3125 | 0.034 | BR-05 | 21505-00 | 1605 NS |
1606 | 0.375 | 0.9062 | 0.3125 | 0.035 | BR-06 | 21506-00 | 1606 NS |
1607 | 0.4375 | 0.9062 | 0.3125 | 0.06 | BR-07 | 21507-00 | 1607 NS |
1614 | 0.375 | 1.125 | 0.375 | 0.077 | BR-14 | 21806-00 | 1614 NS |
1615 | 0.4375 | 1.125 | 0.375 | 0.071 | BR-15 | 21807-00 | 1615 NS |
1616 | 0.5 | 1.125 | 0.375 | 0.066 | BR-16 | 21808-00 | 1616 NS |
1620 | 0.4375 | 1.375 | 0.4375 | 0.11 | BR-20 | 22207-00 | 1620 NS |
1621 | 0.5 | 1.375 | 0.4375 | 0.106 | BR-21 | 22208-00 | 1621 NS |
1622 | 0.5625 | 1.375 | 0.4375 | 0.101 | BR-22 | 22209-00 | 1622 NS |
1623 | 0.625 | 1.375 | 0.4375 | 0.088 | BR-23 | 22210-00 | 1623 NS |
1628 | 0.625 | 1.625 | 0.5 | 0.159 | BR-28 | 22610-00 | 1628 NS |
1630 | 0.75 | 1.625 | 0.5 | 0.143 | BR-30 | 22612-00 | 1630 NS |
1633 | 0.625 | 1.75 | 0.5 | 0.203 | BR-33 | 22810-00 | 1633 NS |
1635 | 0.75 | 1.75 | 0.5 | 0.187 | BR-35 | 22812-00 | 1635 NS |
1638 | 0.75 | 2 | 0.5625 | 0.265 | BR-38 | 23212-00 | 1638 NS |
1640 | 0.875 | 2 | 0.5625 | 0.247 | BR-40 | 23214-00 | 1640 NS |
1641 | 1 | 2 | 0.5625 | 0.221 | BR-41 | 23216-00 | 1641 NS |
1652 | 1.125 | 2.5 | 0.625 | 0.463 | BR-52 | 24018-00 | 1652 NS |
1654 | 1.25 | 2.5 | 0.625 | 0.419 | BR-54 | 24020-00 | 1654 NS |
1657 | 1.25 | 2.5625 | 0.6875 | 0.474 | - | 24120-00 | 1657 NS |
1658 | 1.3125 | 2.5625 | 0.6875 | 0.441 | - | 24121-00 | 1658 NS |
Deep Groove Ball Bearings Widely used in various industries,
our bearings meet the requirements of your project！
1.FREE SAMPLES:
contact us by email or trade manager, we will send the free sampls according to your request.
2. World Class Bearing:We provide our customers with all type of indigenous bearing with world class quality.
3. OEM or Non Stand Bearings: Any requirement for Non standard bearings is Easily Fulfilled by us due to
its vast knowledge and links in the industry.
4. Genuine products With Excellent Quality: Company has always proved the
100% quality products it provides with genuine intent.
5.After Sales Service and technical Assistance: Company provides after sales service and technical assistance
as per the customers requirement and needs.
6. Quick Delivery: The company provides just-in-time delivery with its streamlined supply chain.
7. Cost Saving: We provide long-life, shock-resistant and high reliability bearings with
excellent quality and better performance. Resulting in increased cost saving.
8.Attending customer queries promptly: We believe that if customer are satisfied
then it proves our worth well. Customers are always given quick support.
