Metric Miniature Flanged Ball Bearings

Product Description

BLS bearing can supply all kinds of mini bearings with different material, including chrome steel, stainless steel and ceramic. Except normal miniature bearing, we also can manufacture miniature flange bearing, we accept custom bearing according to customer requirements as well.
Many of these flanged miniature bearings can be supplied to order with ceramic balls (hybrid bearings). Most sizes are available in stainless steel or passivated stainless steel for more corrosive environments.and flange ball bearing can be supplied double flanged.

Inquire Now

Product Details

60 Series Deep Groove Ball Bearings

Deep Groove Ball Bearings

Metric Miniature Flanged Ball Bearings

I have all the models you need, these are just some of them, please contact us now

Product Number	Bore Dia(d)	Outer Dia(D)	Width(B)	Flange Dia (Df)	Flange Width (Bf)	Dynamic Load Rating	Static Load Rating
F681	1 mm	3mm	1mm	3.8mm	0.3mm	82	21
F691	1 mm	4mm	1.6mm	5mm	0.5mm	120	30
MF41x	1.2 mm	4mm	1.8mm	4.8mm	0.4mm	95	26
F681x	1.5 mm	4mm	1.2mm	5mm	0.4mm	95	26
F681xzz	1.5 mm	4mm	2mm	5mm	0.6mm	95	26
F691X	1.5 mm	5mm	2mm	6.5mm	0.6mm	144	40
F691xzz	1.5 mm	5mm	2.6mm	6.5mm	0.8mm	144	40
F601x	1.5 mm	6mm	2.5mm	7.5mm	0.6mm	281	79
F601xzz	1.5 mm	6mm	3mm	7.5mm	0.8mm	281	79
F682	2 mm	5mm	1.5mm	6.1mm	0.5mm	144	40
F682 2RS	2 mm	5mm	2.3mm	6.1mm	0.5mm	144	40
F682zz	2 mm	5mm	2.3mm	6.1mm	0.6mm	144	40
MF52	2 mm	5mm	2mm	6.2mm	0.6mm	144	40
MF52 2RS	2 mm	5mm	2.5mm	6.2mm	0.6mm	144	40
MF52zz	2 mm	5mm	2.5mm	6.2mm	0.6mm	144	40
F692	2 mm	6mm	2.3mm	7.5mm	0.6mm	281	79
F692 2RS	2 mm	6mm	3mm	7.5mm	0.8mm	281	79
F692zz	2 mm	6mm	3mm	7.5mm	0.8mm	281	79
MF62	2 mm	6mm	2.5mm	7.2mm	0.6mm	281	79
MF62 2RS	2 mm	6mm	2.5mm	7.2mm	0.6mm	281	79
MF62zz	2 mm	6mm	2.5mm	7.2mm	0.6mm	281	79
MF72	2 mm	7mm	2.5mm	8.2mm	0.6mm	328	103
MF72 2RS	2 mm	7mm	3mm	8.2mm	0.6mm	328	103
MF72zz	2 mm	7mm	3mm	8.2mm	0.6mm	328	103
F602	2 mm	7mm	2.8mm	8.5mm	0.7mm	328	103
F602 2RS	2 mm	7mm	3.5mm	8.5mm	0.7mm	328	103
F602zz	2 mm	7mm	3.5mm	8.5mm	0.9mm	328	103
F682x	2.5 mm	6mm	1.8mm	7.1mm	0.5mm	178	59
F682x 2RS	2.5 mm	6mm	2.6mm	7.1mm	0.5mm	178	59
F682xzz	2.5 mm	6mm	2.6mm	7.1mm	0.8mm	178	59
F692x	2.5 mm	7mm	2.5mm	8.5mm	0.7mm	328	103
F692x 2RS	2.5 mm	7mm	3.5mm	8.5mm	0.9mm	328	103
F692xzz	2.5 mm	7mm	3.5mm	8.5mm	0.9mm	328	103
MF82x	2.5 mm	8mm	2.5mm	9.2mm	0.6mm	180	67
MF82x 2RS	2.5 mm	8mm	2.5mm	9.2mm	0.6mm	180	67
MF82xzz	2.5 mm	8mm	2.5mm	9.2mm	0.6mm	180	67
F602x	2.5 mm	8mm	2.8mm	9.5mm	0.7mm	469	142
F602x 2RS	2.5 mm	8mm	4mm	9.5mm	0.9mm	469	142
F602xzz	2.5 mm	8mm	4mm	9.5mm	0.9mm	469	142
MF63	3 mm	6mm	2mm	7.2mm	0.6mm	178	59
MF63 2RS	3 mm	6mm	2.5mm	7.2mm	0.6mm	178	59
MF63zz	3 mm	6mm	2.5mm	7.2mm	0.6mm	178	59
F683	3 mm	7mm	2mm	8.1mm	0.5mm	264	90
F683 2RS	3 mm	7mm	3mm	8.1mm	0.8mm	264	90
F683zz	3 mm	7mm	3mm	8.1mm	0.8mm	264	90
MF83	3 mm	8mm	2.5mm	9.2mm	0.6mm	336	113
MF83 2RS	3 mm	8mm	3mm	9.2mm	0.6mm	336	113
MF83zz	3 mm	8mm	3mm	9.2mm	0.6mm	336	113
F693	3 mm	8mm	3mm	9.5mm	0.7mm	474	114
F693 2RS	3 mm	8mm	4mm	9.5mm	0.9mm	474	144
F693zz	3 mm	8mm	4mm	9.5mm	0.9mm	474	144
MF93	3 mm	9mm	2.5mm	10.2mm	0.6mm	485	151
MF93 2RS	3 mm	9mm	4mm	10.2mm	0.6mm	485	151
MF93zz	3 mm	9mm	4mm	10.6mm	0.8mm	485	151
F603	3 mm	9mm	3mm	10.5mm	0.7mm	230	151
F603 2RS	3 mm	9mm	3mm	10.5mm	0.7mm	230	151
F603zz	3 mm	9mm	3mm	10.5mm	1mm	230	151
F623	3 mm	10mm	4mm	11.5mm	1mm	536	175
F623 2RS	3 mm	10mm	4mm	11.5mm	1mm	536	175
F623zz	3 mm	10mm	4mm	11.5mm	1mm	536	175
MF74	4 mm	7mm	2mm	8.2mm	0.6mm	264	92
MF74 2RS	4 mm	7mm	2.5mm	8.2mm	0.6mm	264	92
MF74zz	4 mm	7mm	2.5mm	8.2mm	0.6mm	217	86
MF84	4 mm	8mm	2mm	9.2mm	0.6mm	336	113
MF84 2RS	4 mm	8mm	3mm	9.2mm	0.6mm	336	113
MF84zz	4 mm	8mm	3mm	9.2mm	0.6mm	336	113
F684	4 mm	9mm	2.5mm	10.3mm	0.6mm	545	182
F684 2RS	4 mm	9mm	4mm	10.3mm	1mm	545	182
F684zz	4 mm	9mm	4mm	10.3mm	1mm	545	182
MF104	4 mm	10mm	3mm	11.2mm	0.6mm	604	218
MF104 2RS	4 mm	10mm	4mm	11.6mm	0.8mm	604	218
MF104zz	4 mm	10mm	4mm	11.6mm	0.8mm	604	218
F694	4 mm	11mm	4mm	12.5mm	1mm	814	280
F694 2RS	4 mm	11mm	4mm	12.5mm	1mm	814	280
F694zz	4 mm	11mm	4mm	12.5mm	1mm	814	280
F604	4 mm	12mm	4mm	13.5mm	1mm	814	280
F604 2RS	4 mm	12mm	4mm	13.5mm	1mm	814	280
F604zz	4 mm	12mm	4mm	13.5mm	1mm	814	280
F624	4 mm	13mm	5mm	15mm	1mm	1106	390
F624 2RS	4 mm	13mm	5mm	15mm	1mm	1106	390
F624zz	4 mm	13mm	5mm	15mm	1mm	1106	390
F634	4 mm	16mm	5mm	18mm	1mm	1139	418
F634 2RS	4 mm	16mm	5mm	18mm	1mm	1139	418
F634zz	4 mm	16mm	5mm	18mm	1mm	1139	418
MF85	5 mm	8mm	2mm	9.2mm	0.6mm	262	96
MF85 2RS	5 mm	8mm	2.5mm	9.2mm	0.6mm	185	72
MF85zz	5 mm	8mm	2.5mm	9.2mm	0.6mm	185	72
MF95	5 mm	9mm	2.5mm	10.2mm	0.6mm	366	135
MF95 2RS	5 mm	9mm	3mm	10.2mm	0.6mm	366	135
MF95zz	5 mm	9mm	3mm	10.2mm	0.6mm	366	135
MF105	5 mm	10mm	3mm	11.2mm	0.6mm	366	135
MF105 2RS	5 mm	10mm	4mm	11.6mm	0.8mm	366	135
MF105zz	5 mm	10mm	4mm	11.6mm	0.8mm	366	135
MF115 2RS	5 mm	11mm	4mm	12.6mm	0.8mm	609	226
MF115zz	5 mm	11mm	4mm	12.6mm	0.8mm	609	226
MF115	5 mm	11mm	4mm	12.6mm	0.8mm	609	226
F685	5 mm	11mm	3mm	12.5mm	0.8mm	609	226
F685 2RS	5 mm	11mm	5mm	12.5mm	1mm	609	226
F685zz	5 mm	11mm	5mm	12.5mm	1mm	609	226
F695	5 mm	13mm	4mm	15mm	1mm	916	346
F695 2RS	5 mm	13mm	4mm	15mm	1mm	916	346
F695zz	5 mm	13mm	4mm	15mm	1mm	916	346
F605	5 mm	14mm	5mm	16mm	1mm	1130	406
F605 2RS	5 mm	14mm	5mm	16mm	1mm	1130	406
F605zz	5 mm	14mm	5mm	16mm	1mm	1130	406
F625	5 mm	16mm	5mm	18mm	1mm	1470	540
F625 2RS	5 mm	16mm	5mm	18mm	1mm	1470	540
F625zz	5 mm	16mm	5mm	18mm	1mm	1470	540
F635	5 mm	19mm	6mm	22mm	1.5mm	1986	717
F635 2RS	5 mm	19mm	6mm	22mm	1.5mm	1986	717
F635zz	5 mm	19mm	6mm	22mm	1.5mm	1986	717
MF106	6 mm	10mm	2.5mm	11.2mm	0.6mm	422	174
MF106 2RS	6 mm	10mm	3mm	11.2mm	0.6mm	422	174
MF106zz	6 mm	10mm	3mm	11.2mm	0.6mm	422	174
MF126	6 mm	12mm	3mm	13.2mm	0.6mm	609	236
MF126 2RS	6 mm	12mm	4mm	13.6mm	0.8mm	609	236
MF126zz	6 mm	12mm	4mm	13.6mm	0.8mm	609	236
F686	6 mm	13mm	3.5mm	15mm	1mm	920	354
F686 2RS	6 mm	13mm	5mm	15mm	1.1mm	920	354
F686zz	6 mm	13mm	5mm	15mm	1.1mm	920	354
F696	6 mm	15mm	5mm	17mm	1.2mm	1139	418
F696 2RS	6 mm	15mm	5mm	17mm	1.2mm	1139	418
F696zz	6 mm	15mm	5mm	17mm	1.2mm	1139	418
F606	6 mm	17mm	6mm	19mm	1.2mm	1924	677
F606 2RS	6 mm	17mm	6mm	19mm	1.2mm	1924	677
F606zz	6 mm	17mm	6mm	19mm	1.2mm	1924	677
F626	6 mm	19mm	6mm	22mm	1.5mm	1986	717
F626 2RS	6 mm	19mm	6mm	22mm	1.5mm	1986	717
F626zz	6 mm	19mm	6mm	22mm	1.5mm	1986	717
MF117	7 mm	11mm	2.5mm	12.2mm	0.6mm	387	162
MF117 2RS	7 mm	11mm	3mm	12.2mm	0.6mm	387	162
MF117zz	7 mm	11mm	3mm	12.2mm	0.6mm	387	162
MF137	7 mm	13mm	3mm	14.2mm	0.6mm	460	221
MF137 2RS	7 mm	13mm	4mm	14.6mm	0.8mm	460	221
MF137zz	7 mm	13mm	4mm	14.6mm	0.8mm	460	221
F687	7 mm	14mm	3.5mm	16mm	1mm	997	410
F687 2RS	7 mm	14mm	5mm	16mm	1.1mm	997	410
F687zz	7 mm	14mm	5mm	16mm	1.1mm	997	410
F697	7 mm	17mm	5mm	19mm	1.2mm	1364	575
F697 2RS	7 mm	17mm	5mm	19mm	1.2mm	1364	575
F697zz	7 mm	17mm	5mm	19mm	1.2mm	1364	575
F607	7 mm	19mm	6mm	22mm	1.5mm	1986	717
F607 2RS	7 mm	19mm	6mm	22mm	1.5mm	1986	717
F607zz	7 mm	19mm	6mm	22mm	1.5mm	1986	717
F627	7 mm	22mm	7mm	25mm	1.5mm	2794	1103
F627 2RS	7 mm	22mm	7mm	25mm	1.5mm	2794	1103
F627zz	7 mm	22mm	7mm	25mm	1.5mm	2794	1103
MF128	8 mm	12mm	2.5mm	13.2mm	0.6mm	462	219
MF128 2RS	8 mm	12mm	3.5mm	13.6mm	0.8mm	462	219
MF128zz	8 mm	12mm	3.5mm	13.6mm	0.8mm	462	219
MF148	8 mm	14mm	3.5mm	15.6mm	0.8mm	695	309
MF148 2RS	8 mm	14mm	4mm	15.6mm	0.8mm	695	309
MF148zz	8 mm	14mm	4mm	15.6mm	0.8mm	695	309
F688	8 mm	16mm	4mm	18mm	1mm	1064	474
F688 2RS	8 mm	16mm	5mm	18mm	1.1mm	1064	474
F688zz	8 mm	16mm	5mm	18mm	1.1mm	1064	474
F698	8 mm	19mm	6mm	22mm	1.5mm	1902	734
F698 2RS	8 mm	19mm	6mm	22mm	1.5mm	1902	734
F698zz	8 mm	19mm	6mm	22mm	1.5mm	1902	734
F608	8 mm	22mm	7mm	25mm	1.5mm	2799	1103
F608 2RS	8 mm	22mm	7mm	25mm	1.5mm	2799	1103
F608zz	8 mm	22mm	7mm	25mm	1.5mm	2799	1103
F679	9 mm	14mm	3mm	15.5mm	0.8mm	781	374
F679 2RS	9 mm	14mm	4.5mm	15.5mm	0.8mm	781	374
F679zz	9 mm	14mm	4.5mm	15.5mm	0.8mm	781	374
F689	9 mm	17mm	4mm	19mm	1mm	1128	534
F689 2RS	9 mm	17mm	5mm	19mm	1.1mm	1128	534
F689zz	9 mm	17mm	5mm	19mm	1.1mm	1128	534
F699	9 mm	20mm	6mm	23mm	1.5mm	2097	865
F699 2RS	9 mm	20mm	6mm	23mm	1.5mm	2097	865
F699zz	9 mm	20mm	6mm	23mm	1.5mm	2097	865
F609	9 mm	24mm	7mm	27mm	1.5mm	2853	1155
F609 2RS	9 mm	24mm	7mm	27mm	1.5mm	2853	1155
F609zz	9 mm	24mm	7mm	27mm	1.5mm	2853	1155
