Miniature Metric Bearings

Product Description

Miniature bearings is one kind of deep groove ball bearing, usually we call deep groove ball bearings as small ball bearings when the inner diameter range from 1mm to 10mm, Metric and imperial sizes miniature bearings are included. These miniature bearings have greatly wide range of applied fields including Skateboard, RC Car, Dental, Fishing Reel,Yoyo, Instrument, Electric Motor, Medical and so on.

Inquire Now

Product Details

60 Series Deep Groove Ball Bearings

Deep Groove Ball Bearings

Miniature Metric Bearings

I have all the models you need, these are just some of them, please contact us now

Product Number	Bore Dia (d)	Outer Dia	Width	Dynamic Load Rating	Static Load Rating
R09	0.04 inch	0.1250 inch	0.0469 inch	20	5
R0	0.0469 inch	0.1562 inch	0.0625 inch	21	6
R0zz	0.0469 inch	0.1562 inch	0.0937 inch	21	6
R1	0.055 inch	0.1875 inch	0.0781 inch	44	12
R1zz	0.055 inch	0.1875 inch	0.1094 inch	44	12
R1-4	0.0781 inch	0.2500 inch	0.0937 inch	54	17
R1-4 2RS	0.0781 inch	0.2500 inch	0.1406 inch	54	17
R1-4zz	0.0781 inch	0.2500 inch	0.1406 inch	54	17
R1-5	0.0937 inch	0.3125 inch	0.1094 inch	106	32
R1-5 2RS	0.0937 inch	0.3125 inch	0.1406 inch	106	32
R1-5zz	0.0937 inch	0.3125 inch	0.1406 inch	106	32
R133	0.0937 inch	0.1875 inch	0.0625 inch	36	11
R133 2RS	0.0937 inch	0.1875 inch	0.0937 inch	36	11
R133zz	0.0937 inch	0.1875 inch	0.0937 inch	36	11
R144	0.125 inch	0.2500 inch	0.0937 inch	54	17
R144 2RS	0.125 inch	0.2500 inch	0.1094 inch	54	17
R144zz	0.125 inch	0.2500 inch	0.1094 inch	54	17
R2	0.125 inch	0.3750 inch	0.1562 inch	121	39
R2 2RS	0.125 inch	0.3750 inch	0.1562 inch	121	39
R2zz	0.125 inch	0.3750 inch	0.1562 inch	121	39
R2-5	0.125 inch	0.3125 inch	0.1094 inch	107	32
R2-5 2RS	0.125 inch	0.3125 inch	0.1406 inch	107	32
R2-5zz	0.125 inch	0.3125 inch	0.1406 inch	107	32
R2-6	0.125 inch	0.3750 inch	0.1094 inch	122	41
R2-6 2RS	0.125 inch	0.3750 inch	0.1406 inch	122	41
R2-6zz	0.125 inch	0.3750 inch	0.1406 inch	122	41
R2A	0.125 inch	0.5000 inch	0.1719 inch	122	41
R2A 2RS	0.125 inch	0.5000 inch	0.1719 inch	122	41
R2Azz	0.125 inch	0.5000 inch	0.1719 inch	122	41
R155	0.1562 inch	0.3125 inch	0.1094 inch	69	27
R155 2RS	0.1562 inch	0.3125 inch	0.1250 inch	69	27
R155zz	0.1562 inch	0.3125 inch	0.1250 inch	69	27
R156	0.1875 inch	0.3125 inch	0.1094 inch	69	27
R156 2RS	0.1875 inch	0.3125 inch	0.1250 inch	69	27
R156zz	0.1875 inch	0.3125 inch	0.1250 inch	69	27
R166	0.1875 inch	0.3750 inch	0.1250 inch	136	49
R166 2RS	0.1875 inch	0.3750 inch	0.1250 inch	136	49
R166zz	0.1875 inch	0.3750 inch	0.1250 inch	136	49
R3	0.1875 inch	0.5000 inch	0.1562 inch	249	88
R3 2RS	0.1875 inch	0.5000 inch	0.1960 inch	249	88
R3zz	0.1875 inch	0.5000 inch	0.1960 inch	249	88
R3A 2RS	0.1875 inch	0.6250 inch	0.1960 inch	283	112
R3Azz	0.1875 inch	0.6250 inch	0.1960 inch	283	112
R3A	0.1875 inch	0.6250 inch	0.1960 inch	283	112
R168	0.25 inch	0.3750 inch	0.1250 inch	71	31
R168 2RS	0.25 inch	0.3750 inch	0.1250 inch	71	31
R168zz	0.25 inch	0.3750 inch	0.1250 inch	71	31
R188	0.25 inch	0.5000 inch	0.1250 inch	207	80
R188 2RS	0.25 inch	0.5000 inch	0.1875 inch	207	80
R188zz	0.25 inch	0.5000 inch	0.1875 inch	207	80
R4	0.25 inch	0.6250 inch	0.1960 inch	283	112
R4 2RS	0.25 inch	0.6250 inch	0.1960 inch	283	112
R4zz	0.25 inch	0.6250 inch	0.1960 inch	283	112
R4A	0.25 inch	0.7500 inch	0.2188 inch	446	161
R4A 2RS	0.25 inch	0.7500 inch	0.2812 inch	446	161
R4Azz	0.25 inch	0.7500 inch	0.2812 inch	446	161
R1810	0.3125 inch	0.5000 inch	0.1562 inch	104	50
R1810 2RS	0.3125 inch	0.5000 inch	0.1562 inch	104	50
R1810zz	0.3125 inch	0.5000 inch	0.1562 inch	104	50
R6	0.375 inch	0.8750 inch	0.2188 inch	637	256
R6 2RS	0.375 inch	0.8750 inch	0.2812 inch	637	256
R6ZZ	0.375 inch	0.8750 inch	0.2812 inch	749	301

Deep Groove Ball Bearings

Deep Groove Ball Bearings Widely used in various industries, our bearings meet the requirements of your project！

60 Series Deep Groove Ball Bearings

Deep Groove Ball Bearings

1.FREE SAMPLES:
contact us by email or trade manager, we will send the free sampls according to your request.

2. World Class Bearing:We provide our customers with all type of indigenous bearing with world class quality.

3. OEM or Non Stand Bearings: Any requirement for Non standard bearings is Easily Fulfilled by us due to
 its vast knowledge and links in the industry.

4. Genuine products With Excellent Quality: Company has always proved the
 100% quality products it provides with genuine intent.

5.After Sales Service and technical Assistance: Company provides after sales service and technical assistance
 as per the customers requirement and needs.

6. Quick Delivery: The company provides just-in-time delivery with its streamlined supply chain.

7. Cost Saving: We provide long-life, shock-resistant and high reliability bearings with
 excellent quality and better performance. Resulting in increased cost saving.

8.Attending customer queries promptly: We believe that if customer are satisfied then it proves our worth well.
Customers are always given quick support.

Deep Groove Ball Bearings
