Three Row Cylindrical Rollers Slewing Bearings

Short Description:

BLS slewing ring bearings can support radial, axial and tilting moment loads acting either singly or in combination and in any direction.Therefore, it is possible to replace the combination arrangement of radial and axial bearings by a single bearing, which will measurably reduce the overall cost and simplify the design. Slewing rings are sealed on both sides,lubricated with high quality grease, can be relubricated via lubrication nipples and are particularly easy to install.BLS slewing ring bearings are available in many designs with internal, external or without gear. The low cross section, heavy load capacity and integrated gear make these bearings ideal structure components.Slewing ring bearings are widely used in construction machinery, mining equipment and many other industrial products.

Inquire Now Next Product

Product Details

Deep Groove Ball Bearings

I have all the models you need, these are just some of them, please contact us now

Bearing Code	D	d	H	h1	h2	n4	Du	Dn	n	Φ	d2	T	L	x	m	De	Z
	mm						mm						mm
SN-1000.20	1146	844	128	26	10	4	1094	894	28	26	M24	45	98	0.5	10	790	80
SN-1120.20	1266	964	128	26	10	4	1214	1014	32	26	M24	45	98	0.5	12	900	76
SN-1250.20	1396	1094	128	26	10	4	1344	1144	36	26	M24	45	98	0.5	12	1030	87
SN-1400.20	1546	1240	128	26	10	4	1494	1274	36	26	M24	45	98	0.5	14	1162	84
SN-1600.20	1746	1444	128	26	10	4	1694	1494	40	26	M24	45	98	0.5	14	1372	99
SN-1600.25	1782	1400	148	30	10	8	1716	1474	32	33	M30	56	110	0.5	14	1330	96
SN-1800.25	1982	1600	148	30	10	8	1916	1674	36	33	M30	56	110	0.5	16	1520	96
SN-2000.25	2182	1810	148	30	10	8	2116	1874	44	33	M30	56	110	0.5	16	1728	109
SN-2240.25	2422	2040	148	30	10	8	2356	2114	48	33	M30	56	110	0.5	18	1944	109
SN-2240.32	2458	2000	182	42	10	10	2680	2086	40	39	M36	66	130	0.5	18	1908	107
SN-2500.25	2682	2310	148	30	10	8	2616	2374	54	33	M30	56	110	0.5	18	2214	124
SN-2500.32	2718	2270	182	42	10	10	2640	2346	44	39	M36	66	130	0.5	18	2178	122
SW-1000.20	1156	854	128	26	10	4	1106	906	28	26	M24	45	98	0.5	10	1210	118
SW-1120.20	1280	974	128	26	10	4	1226	1026	32	26	M24	45	98	0.5	12	1344	109
SW-1250.20	1410	1104	128	26	10	4	1356	1156	36	26	M24	45	98	0.5	12	1476	120
SW-1400.20	1560	1254	128	26	10	4	1506	1306	36	26	M24	45	98	0.5	14	1638	114
SW-1600.20	1760	1454	128	26	10	4	1706	1506	40	26	M24	45	98	0.5	14	1834	128
SW-1600.25	1790	1418	148	30	10	8	1726	1484	32	33	M30	56	110	0.5	14	1862	130
SW-1800.25	2000	1618	148	30	10	8	1926	1684	36	33	M30	56	110	0.5	16	2080	127
SW-2000.25	2190	1818	148	30	10	8	2126	1884	44	33	M30	56	110	0.5	16	2272	139
SW-2240.25	2430	2058	148	30	10	8	2366	2124	48	33	M30	56	110	0.5	18	2520	137
SW-2240.32	2464	2022	182	42	10	10	2394	2100	40	39	M36	66	130	0.5	18	2556	139
SW-2500.25	2700	2318	148	30	10	8	2626	2384	54	33	M30	56	110	0.5	18	2790	152
SW-2500.32	2730	2282	182	42	10	10	2654	2360	44	39	M36	66	130	0.5	18	2826	154

Deep Groove Ball Bearings

Deep Groove Ball Bearings Widely used in various industries, our bearings meet the requirements of your project！

Deep Groove Ball Bearings

1.FREE SAMPLES:
contact us by email or trade manager, we will send the free sampls according to your request.

2. World Class Bearing:We provide our customers with all type of indigenous bearing with world class quality.

3. OEM or Non Stand Bearings: Any requirement for Non standard bearings is Easily Fulfilled by us due to
 its vast knowledge and links in the industry.

4. Genuine products With Excellent Quality: Company has always proved the
 100% quality products it provides with genuine intent.

5.After Sales Service and technical Assistance: Company provides after sales service and technical assistance
 as per the customers requirement and needs.

6. Quick Delivery: The company provides just-in-time delivery with its streamlined supply chain.

7. Cost Saving: We provide long-life, shock-resistant and high reliability bearings with
 excellent quality and better performance. Resulting in increased cost saving.

8.Attending customer queries promptly: We believe that if customer are satisfied then it proves our worth well. Customers are always given quick support.
